0-30V 2mA-3A Adjustable DC Regulated Power Supply Laboratory Power Supply(not soldered)

product description The circuit voltage can be from 0V, the output current can be continuously adjustable from 2 to 3μA, set the output current, if the experimental circuit exceeds the current (including short circuit), the circuit is immediately protected, not dangerous, such as burners, is the electronics manufacturing Effective assistant. This is fireworks that have never been scared! Like making a variety of audio circuit friends, often due to different operating voltage and the circuit and feel a headache, this circuit can also be two series into a dual power supply to meet the needs of various purposes. All the inline components make it easy to have only one adjustable component (for adjusting the voltage 0 V) LED for overcurrent output, LED lighting, overload and short circuit protection when current exceeds set data circuit protection Minimum current (2mA) under measurable LED and Zener diode Input voltage: 24V AC Input current: up to 3A Output voltage: 0 ~ 30V continuously adjustable Output current: 2mA - 3A continuously adjustable Output voltage ripple: 0.01% minimum note: Power supply is high-voltage high-current circuit, be sure to be careful, otherwise it may cause personal safety damage Package contains: 1 x adjustable DC power supply DIY kit
