Parameter Symbol Absolute Maximum Rating Unit Forward Current IF 20 mA Peak pulse Current (1/10 Duty cycle,Pulse width=0.1msec ) IFP 50 mA Reverse Voltage VR 5 V Power Dissipation (at room temperature) PD 60 mw Operating Temperature TOPR -20~+85 ℃ Storage Temperature TSTG -30~+80 ℃ Soldering Temperature TSOL Reflow Soldering: 200℃ for 5 sec Hand Soldering: 240℃ for 3 sec Item Symbol Condition Min Typ Max Unit Forward Voltage VF IF=20mA R 1.8 2.1 2.4 V G 2.8 3.1 3.4 B 2.8 3.1 3.4 Light intensity IV IF=20mA R 250 300 350 mcd G 900 1000 1100 B 200 250 300 Wavelength WD IF=20mA R 620 623 625 nm G 520 522 525 B 465 467 470 Luminous Flux Φ IF=20mA R 0.8 1.0 1.2 lm G 3.8 4.0 4.3 B 0.8 0.9 1.0 Reverse current IR IF=20mA
5 uA Viewing Angle 2θ1/2 IF=20mA
120 deg Recommend Forward Current IF(rec) IF=20mA
20 mA
