STM32F746G-DISCO 32F746GDISCOVERY ARM STM32F429IGT6 STM32 Development Board Core Board + PL2303 Module

STM32F746G-DISCO 32F746GDISCOVERY ARM STM32F429IGT6 STM32 Development Board Core Board + PL2303 Module STM32F746G-DISCO 32F746GDISCOVERY STM32F429IGT6 STM32 development board core board + PL2303 module [Core interface] Core board slot Easy access to the core board. USART3 interface Easy access to RS232, RS485, TO USB 232 modules. DCMI interface Convenient camera module. Capacitive touch screen interface Convenient access to capacitive touch screen. CAN2 interface Easy access to CAN module. CAN1 interface Easy access to CAN module. SDIO interface Easy access to SD Micro module, SDIO interface to read and write SD card faster than the speed of the SPI interface. ULPI interface Easy access to high-speed USB modules, etc. (STM32F429I does not have built-in HS PHY USB). LCD interface Easy access to the LCD 7 inches. 1-WIRE interface Easy access to 1-WIRE devices (TO-92 package) such as temperature sensor DS18B20, electronic registration number DS2401 and more. LCD interface 2 Easy access to the LCD 4.3 inches. I2C2 / I2C3 interface Easy access to I2C modules, such as I / O expansion chip EEPROM, AT24CXX PCF8574 module. SAI1 interface Easy access to audio modules, such as the UDA1380 module. Ethernet interface Easy access to Ethernet module. USB interface After the board USB TO UART PL2303 chip conversion, converted to UART. SPI1 / SPI2 interface Easy access to the SPI module, such as AT45DBXX FLASH, SD card, MP3 module. Easy access to DA, AD modules because SPI1 reuses AD, DA functions. I2S2 / I2S3 / I2C1 interface Easy access to I2S modules, such as audio modules. FMC + SPI 16BIT interface Convenient LCD + touch screen module. [Other interface] DC 5V interface 5V and 3.3V power input and output interfaces Commonly used in external power supply, or co-processing with the user board. MCU pin interface Resulting in I / O, convenience, and peripheral I / O connections. [chip] PL2303 USB serial chip. [Device Profile] User LED Convenient I / O output test or display program running status. TX-LED PL2303 / RX-LED 12MHZ crystal Serial port for PL2303 crystal. Rocker Up, down, left, right, news, a total of five states. UP WAKE button Can be used as a normal button, you can wake the STM32 from sleep. [Description] jump shot USB TO UART jumper User LED jumper Short jumpers: access to the specified I / O sample program; Disconnect jumpers: Can be modified to use custom I / O connection lines to access. User / Five rocker jumper key Short jumpers: access to the specified I / O sample program; Disconnect jumpers: Can be modified to use custom I / O connection lines to access.
