Stepper Motor 0.6A 0.12Nm 28mm 1.8 42
Description:
HANPOSE 17HS2408 28mm Nema 17 Stepper Motor 42 Motor 42BYGH 0.6A 12N.cm 4-lead For CNC Laser 3D Printer Motor
Certification: CE, ROSH, ISO, FCC
Specification:
Model 17HS2408
Phase 2
Step Angle 1.8°
Motor Size 42 x 28mm
Shaft "Round" shaft 21xФ5MM
Outlet way "4" plug line
Adapter drive Two-phase step drive
Scope 3D Printers, Monitor Equipment, Medical Machinery, Textile Machinery,
Packaging Machinery, Stage Lighting, Laser engraving, Automation
Equipment, Non-standard Equipment, Placement machine ect.
Electrical Specifications:
Step Angle(Deg) :1.8
Motor Length (mm) :28
Rated Current(A) :0.6
Resistance Phase(Ohm) :8
Phase Inductance(mH) :10
Holding Torque(N. cm):12
Couple Relaxing(N.cm) :1.6
Inertia Of Rotor(G. cm²):34
Lead (No.):4
General Specification:
Precision angle step: ±5% (full step, no charge)
Resistance accuracy: ±10%
Precision inductance: ±20%
Temperature rise: 80deg Max (rated current, 2 phase on)
Ambient temperature: ( - 20°)-(+ 50°)
Insulation resistance: 100MΩ Min, 500VDC
Insultion Force: 500VAC for a minute
