sensor sht10

Product features
Digital, the resolution is up to 14bit.
Internal self calibration.
The temperature and humidity are closely combined, convenient for dew point measurement.
High reliability and long term stability.
The product structure is exquisitely, suitable for field application and product integration.
Product description
Soil temperature and humidity probe using the original temperature and humidity sensors as the core component, can be directly connected to the single-chip microcomputer to use .With very high
consistency, can be completely interchangeable. the probe has the characteristic of temperature resistance, pressure resistance, loss of ability, suit to the agricultural greenhouse, flowers, nursery
garden, lawn and other need detection of soil temperature and humidity environment occasions.
Features:
Digital, the resolution is up to 14bit.
Internal self calibration.
The temperature and humidity are closely combined, convenient for dew point measurement.
High reliability and long term stability.
The product structure is exquisitely, suitable for field application and product integration.
Applied in the agricultural greenhouse, flowers, nursery garden, lawn and other need detection of soil temperature and humidity environment occasions.
Specifications:
Type: temperature and humidity
Production process: integration
Output signal: numeric type
Technical parameters:
Working voltage: 3.3-5V
Operating current: ≤15mA
Temperature measuring range: - 20 ℃ ~ 100 ℃
Humidity measuring range: 0 ~ 100 % RH
Working conditions: - 20 ℃ ~ 90 ℃, 0 ~ 99% RH
Storage conditions: - 20 ℃ ~ 80 ℃, 0 ~ 95% RH
Weight: 70g
Package Included:
1 x FS200-SHT10 Soil temperature and humidity sensor
