Ethernet | Standard:10/100Base-T(x) Speed:10/100M auto-sensing Working: TCP Server, TCP Client, UDP and Real COM driver Memory: Most 32Kbyte Transmission: 100m Electromagnetism isolate: 1KV Connector: RJ45 |
Serial | Standard: RS-232/RS-485/RS-422 Signals: RS-232:DCD,RXD,TXD,DTR,GND,DSR,RTS,CTS RS-485:Data+,Data-,GND RS-422:TXD+,TXD-,RXD+,RXD-,GND Working mode: Asynchronous format, point to point, 2 wires half duplex, 4 wires full duplex Parity: None, Even, Odd, Space, Mark Data bits: 7bit, 8bit Baud rate: 300bps ~ 115.2Kbps Flow control: RTS/CTS Direction control: RS485 side adopt ADDC technology, auto text and control data transfer direction Loading: RS-485/422 side support 32 nodes (customize 128 nodes) loopback Transmission: RS-485/422 side 1200M, RS-232 port 15M Interface protection:1500W surge protection, 15KV ESD protection |
