Product Description
Housing GLASS FILLED POLYESTER(UL94V-0)
Contact PHOSPHOR BRONZE 0.46mm (C5100)
Rated current 1.5A
Rated voltage 125 VAC RMS
Contact resistance 50 MILLIOHMS MAX.
Insulation resistance 500 MEGOHMS MIN 500V DC
LED RATING FORWARD VOLTAGE 2.2 VOLTS TYPICAL
LED RATING REVERSE VOLTAGE 5 VOLTS MAXIMUM
ENVIRONMENTAL STORAGE -40℃ TO +85℃
ENVIRONMENTAL OPERATION -20℃ TO +70℃
DURRABILITY 750 CYCLES MIN
