NanoPi-M2 4418 quad-core A9 open source development board boxes sent Gigabit Ethernet 1GB memory AXP228

The NanoPi M2 is another 4418-based ARM board released by FriendlyARM following the NanoPi 2 and NanoPi 2 Fire. This is only two-thirds of the raspberry pie. It is open source. It works with Ubuntu Core, Ubuntu Mate, Debian, Android 5.1 and more use together. Compared to the Raspberry Pi 2,  Cortex-A9 S5P4418 Soc. It integrates Gbps Ethernet, AXP228 PMU with software power-on / power-off and wake-up capabilities. It can be powered through the MicroUSB port On such a small board, it still integrates rich interfaces and ports. In addition to the popular HDMI, 3.5mm audio jack, on-board microphone, 4 USB host and Gbit Ethernet, it also features Raspberry Pi compatible 40-pin GPIO pin header and a variety of video interfaces such as DVP cameras Interface, an LCD interface that supports I2C capacitive LCDs and, in addition, a user-friendly serial debug port for debugging and development. Features CPU: S5P4418, 400Mhz ~ 1.4GHz PMU power management unit: AXP228, software shutdown, sleep and wake-up function DDR3 RAM: 32bit 1GB DDR3 MicroSD slot x1 Connection: Gbps Ethernet port (RTL8211E) Audio: 3.5mm audio jack / via HDMI Microphone: 1 x onboard microphone USB Host: Four USB 2.0 Hosts, Two Standard A-Ports and Two Other 2.54mm Pins Micro USB: 1 USB 2.0 client LCD Interface: 0.5 mm pitch SMT FPC base for full color LCD: 8-8-8) HDMI: HDMI 1.4A, Type-A, 1080P60 DVP camera interface: 0.5mm pitch FPC socket. It includes 8 bits of ITU-R BT 601/656, I2C and IO GPIO1: 40pin at 2.54mm pitch, compatible with the GPIO of the Raspberry Pi. It includes UART, SPI, I2C, PWM, IO and so on Debug serial port: 4Pin 2.54mm pitch pin connector User key: 1 power supply, 1 reset LED: 1 power LED, 1 system LED RTC: RTC pin Power: DC 5V / 2A PCB size (mm): 64 x 56, six layers Operating System / Software: u-boot, Android 5.1, Debian Jessie 8
