LM2596HVS-AD Power Supply Step-Down Module for Arduino

Regulated power supply, only the module input port connected to the car cigarette lighter power supply, you can adjust the potentiometer, the output voltage can be 4.5V ~ 45V, can be adjusted (due to the buck module, the output voltage lower than the input voltage 1.5V or higher )
- For mobile phones, MP3, MP4, PSP and other equipment power supply
- Input mode: IN + input plus, IN- input negative
- Output mode: OUT + output, OUT- output minus
- Adjust the method: after the input power supply the first right (4.5 ~ 45V), and use the multimeter to monitor the output voltage and adjustable potentiometer (usually turn the boost voltage in time, inverse time to decompression), the output voltage V)
- Continuously adjustable
- the smallest. Voltage: 1.5V
- Input Power: 2A, 12V to 5V 3A (max), 15W
- Conversion efficiency: up to 92% (the higher the output voltage, the higher the efficiency)
- Static power consumption: only about 6mA
- Connection: welding
- Operating temperature: technical grade (-40'C ~ 85'C), load regulation: +/- 1%, voltage regulation: +/- 0.5%
- packing list:
- 1 step-down module

Size: (3.4 cm × 2.2 cm × 1.3 cm)
Weight: (12 grams)
