GY-26 electronic compass module, electronic compass module, robot accessories

Product description GY-26 Electronic Digital Compass Sensor Module GPS Navigation 3V-5V DC Robot Accessories Description: GY-26 is a plane digital compass module with low cost. Its size is small, the input voltage and power consumption is low. Its working principle is using two mutually perpendicular magnetic sensor axes simultaneously sense the Earth's magnetic field component to derived azimuth angle. The compass communicate with other devices by RS232 and IIC protocol. High precision and high stability. With re-calibration function, it can get an accurate position in any position. The output of the baud rate is 9600bps. Two ways of output, continuous and inquiries. With magnetic declination compensation function, can adapt to different working environment. Feature: Operating voltage: DC 3V - 5V Operating current: 5V 15mA, 3V 8mA Measuring range: 0?? - 360?? Resolution: 0.1?? Measuring precision: 1?? Repeatability precision: 1?? Response frequency: 25Hz Working temperature: -20??C to +85??C Store temperature: -40??C to + 125??C Size: 2.5 x 2.5cm(L x W) Application: Handheld electronic instrument Robot orientation and position Navigation system Telescope position Auto helm rudder Antenna position Automobile GPS navigation Aero model position Package included: 1 x Digital compass module
