FC-26P 2.54 Header
Specifications：
Type: FC-26P
Row Number: 2
Pin/Position Number: 26
Connector Type: IDC Female
Pitch: 2.54mm/0.1"
Total Size: 38 x 17 x 6mm/1.5" x 0.67" x 0.24" (L*W*H)
Color: White
Material: Plastic, Metal
Insulator Material: Polyester(UL94V-0)
Contact Material: Brass
Current Rating: 3A
Operation Temperature: -40℃ to +105℃
Contact Resistance: 20mΩ Max.at DC 100mA
Insulation Resistance: 1000MΩ Min.at 500V DC
Withstand Voltage: AC 1000V
Weight: 41g
