Input voltage: DC 8-35V
? Input current: 5.5A ? Output voltage: 5.2V ? Output current: total maximum 8A, current adaptive, mobile phone single port charging up to 2A. ? Dynamic response speed: 300us (load flow change 5%) ? Conversion efficiency: 95% (12V to 5.2V3.5A measured, efficiency is related to differential pressure and load size.) ? Load regulation rate: 0.2-0.3% (10%-50% load measured by 12V input) ? Ripple & Noise: 120mVP-P (20MHz bandwidth 12V to 5.2V3A measured) ? Switching frequency: 100KHz ? No-load current: 18mA (12V car 5V measured) ? Wiring method: IN input OUT input Terminal block DC seat ? Fixed mode: M3*1 M2*2 ? Net weight: about 36 grams
