DB-268 G1/2 Output:0-12V Hydro

DB-268 G1 / 2 Output: 0-12V Hydro
DB-268 G1 / 2 Output: 0-12V Hydro
The basic parameters: the output voltage AC 0-20V, the output current 0-150MA, the flow range of 3-18L per minute, the pressure range of 0.15-0.8MPA
Dual line output voltage DC5V
Technical Parameters
The maximum working pressure is 1.2 MPa
Working pressure 0 ~ 1.0 Mpa
The test pressure is 0.6MPa
Temperature range 0 ~ 80 ° C
Maximum allowable ambient temperature 100 ° C Maximum: 30 minutes
Storage temperature -25 ~ 65 ° C
Flow range 3.5 ~ 20L / min (pressure 0.05-0.2mpa)
Maximum output DC6V Water flow 15 L / min,
Output voltage DC5V Water flow 4L / min
Flow DC2.5 start water flow output voltage of 3.5L / min
