Temperature Range
-55~+155℃(PE Cable -40~+85)
Vibration
100m/S2 (10-500Hz), 10g
Impedance
50 Ω, 75Ω
Frequency Range
DC -4GHz
Working Voltage
500V r.m.s at sea level
Withstanding Voltage
1500V r.m.s at sea level
Contact Resistance
Center contact
≤1.5m Ω
Outer contact
≤1m Ω
Contact Pin
Brass-Au / Ag plated
Insulation resistance
≥5000M Ω
Center Conductor Retention Force
≥0.57N
Voltage Standing Wave Ratio
Straight
≤ 1.22/3GHZ
Right angle
≤ 1.30/3GZ
Durability(mating)
≤500cycles
Body
Brass--Ni plated
Contact
Beryllium copper
Insulator
PTFE
