8232 Ad8232 Ecg Measurement Module

Product Features Electronic module product description If you need more details, please contact us. 8232 Sensor Module Single-Boot Heart Rate Monitor Front End The AD8232 is an integrated front-end for sending signals to cardiac bioelectric signals. Regulation of heart rate monitoring. Integrated signal conditioning module for ECG and other bioelectric measurement applications. The device is designed to extract, amplify and filter bioelectric signals and place the resulting noise using mobile or remote electrodes. The design allows ultra-low-power analog-to-digital converters (ADCs) or embedded microcontrollers to easily capture the output signal. The AD8232 uses bipolar high-pass filters to eliminate motion artifacts and half-cell potentials. The filter is tightly coupled with the instrumentation amplifier architecture to provide single-stage high-gain and high-pass filtering, saving space and cost. The AD8232 uses an unconstrained op amp to create a triode low-pass filter that eliminates additional noise. By selecting the cut-off frequency of all filters, users can meet the needs of different types of applications. To improve system line frequency and other adverse interference common mode rejection performance, the AD8232 has a built-in right-side driver amplifier (RLD). The AD8232 has a fast recovery feature that reduces the long-term passage of the original high-pass filter. If the amplifiers supply voltage is abrupt (eg, derived), the AD8232 automatically adjusts to a higher filter cutoff. This feature allows the AD8232 to achieve fast recovery,
