description:
- 5A constant current and step-down module with MPPT control. - Effectively shorten the solar battery charging time. - Conversion efficiency up to 95%, improve charging efficiency. - Battery, lithium battery, etc. can be charged with turn signal control. - Powering mobile phones or various digital products as on-board power to drive high-power LEDs. specification: - Attributes: Non-Isolated Buck Module (BUCK) - Input voltage: 6-36V - Output voltage: 1.25-32V continuously adjustable (default output 5V) - MPPT voltage setting range: 6-36V - Output current range: 0.05-5A (the default output current of 3A, for a long time within 3A) - Turn signal output range: 0.01-5A (default 0.3A), the current range will be slightly different due to the wrong parameters of each part. - Multi-function dual display: input voltage, output voltage, output current, output power - Operating temperature: -40 to +85 degrees - Working frequency: 180KHz - Conversion efficiency: up to 95% (efficiency versus input voltage, output voltage, current and voltage difference) - Short circuit protection: yes - Over-temperature protection: yes (automatic shutdown output after over-temperature) - Input Reverse Polarity Protection: None (Please add diode string if necessary) - Installation: 3mm screws (4) - Connection: Terminal, IN input, OUT output - Size: 60 * 31 * 22 mm (L * W * H) Package includes: 1 MPPT DC-DC step-down converter note: The current test module is a low-end test, please do not directly connect the input negative and negative output!
