30KG Servo DS3230 RED 90Degree/270degree
Description:
Item: DS3230 Digital Servo
Operating Voltage: DC6.0~7.4V
Operating Speed (6.0V): 0.13sec/60 degrees
Operating Speed (7.4V): 0.11sec/60 degrees
Stall Torque (6.0V): 30kg.cm (239.05oz/in)
Stall Torque (7.4V): 32kg.cm (294.75oz/in)
Working Frequence: 1500μs/330hz
Teeth: 25T
Motor: Coreless motor
Bearing: 2BB
Dead band: 2μs default
Waterproof: Yes
Connector Wire Length: JR320 mm (12.6in)
Weight: 89g (2.19oz)
Dimensions: 40.2X20X41mm /1.58X0.79X1.61 in
Features:
- High performance programmable digital high voltage standard servo
- High-precision Taiwan-made aluminium gears with hard anodizing
- High quality coreless motor
- Middle CNC aluminium case
- Dual ball bearings
- Waterproof
