1Meter RJ45 Internet Cable

Num :

ID-FPC-002

Item :

Cat 6 UTP Flat patch cord

Brand :

Idex

Conductor :

32AWG stranded copper

Path Cord Plug :

Unshielded RJ-45 Plug

Boot :

FR PVC High injection

Jacket :

PVC/LSZH

Impedance :

100ohms ± 15%, IMHz to 600MHz

Transport delay:

536ns/100mmax. @ 250MHz

Delay offset:

45ns max

Conductor resistance:

66.58 ohms max / km

Capacitance:

5.6NF max/100m

DC Resistance:

≤7.55&Omega

Pressure:

300 volts AC DC

Bend radius:

5MM

U / NEC level:

CMR, CM

Operating temperature:

-20 degree to 60 degree range

Storage temperature:

-20 degree to 80degree between
