12V/5V 2.5A USB to IDE/SATA Power Supply Adapter Hard Drive/HDD/CD-ROM AC DC

Output voltage: DC 12V and 5V

Support: 3.5-inch IDE hard drive, 5.25-inch IDE optical drive, etc. It can also support SATA hard drive but need to purchase a SATA power extension cable

Current: 2000MA (foot 1.5A)

Current: 2000MA (foot 2A)

Power supply description

1: This power supply is a high-quality point 2A (foot 1.5A) power supply. The most popular power supply on the market is of good quality. It is suitable for connecting small-capacity hard disks, such as 500G. If you have a large capacity or a higher requirement, it is recommended to purchase a 2.5A L-type stripe type power supply.

Product Specifications:

1. Input voltage range AC100-240V.

2. Input voltage frequency: 50-60Hz.

3. Output voltage 12V/5V

4. Output voltage adjustment rate: 5%.

5. Rated output current 2A

6. Current output range 0-2A (working time above 2A does not exceed 5 minutes).

7. Output ripple & noise 100mVp-p.

8. Working efficiency 80-85%.

9. Working temperature 0 °C ~ +50 °C.

10. Storage temperature -20 ° C ~ +85 ° C

11. Output short circuit protection.

12. Input plug specifications: AC socket suffix

13. Output line length is 0.5 meters (can be customized)

14. Output DC head: 4 holes

Product Features:

1, the global universal full range AC input voltage

2, good anti-interference performance, high reliability

3, DC ripple is small, high work efficiency

4, low operating temperature, long service life

5, small size, high power density

6, good insulation performance, high electrical strength

7, full load high temperature burning machine, 100% aging test

8, with short circuit protection / overload protection / over voltage protection
