product description
Summary: It converts RCA (AV, Composite, CVBS) signals to HDMI signals so you can watch your video on a modern TV with an HDMI port. The analog-to-digital conversion in this module uses 10-bit maximum 162MSPS sampling, black / white level expansion, color conversion improvement, dynamic range expansion, blue stretching, automatic detection and automatic conversion of composite signals to 1080p (60Hz) output. Get your videos active and deliver the clearest and most realistic HD visual effects. Product Specifications: 1. Input ports: 1xRCA (yellow, white, red), USB power 2. Output port: 1xHDMI (standard) 3. Compatible with NTSC / PAL 4. Composite Input: PAL, NTSC3.58, NTSC4.43, SECAM, PAL / M, PAL / N 5. HDMI output: 1080p / 60Hz, 720p / 60Hz 6. Size (mm): 66 (D) x55 (W) x20 (H) 7. Weight (g): 40 grams 8. Power: USB port feature: No need to install drivers, portable, flexible, plug and play. Support PAL, NTSC3.58, NTSC4.43, SECAM, PAL / M, PAL / N and other standard TV system input. Video output audio synchronization. High bandwidth capability can be displayed on Moniter / TV at 1920x1080 @ 60Hz Note: You may encounter less than three seconds of delay. Do not convert audio only. Important: All cables must be connected and in use (yellow: video, white: left channel and red: right channel) for proper operation of the converter. Supported audio formats: 2-channel analog audio, does not support 3D.
